Piab B75.20.07UH / 0128553

Piab’s silicone bellow suction cup is designed for superior flexibility and adaptability in challenging material handling tasks. The soft silicone construction ensures a gentle grip. Its bellow design allows for excellent compensation of height difference.

$96.39
Part Numbers
  • B75.20.07UH
  • 0128553
Highlights...

Features

  • Made from high quality silicone for safe and efficient handling
  • Suitable for level adjustment.
  • Several short bellows in one lifting device can handle objects with height differences and varying shapes, for example embossed or corrugated plates.
  • The lifting movement can be used to separate small and thin objects.
  • Suitable for plastics, sheet metal and packaging application
  • Material Temperature Max: 392 °F
  • Fitting Size: 1/4" mm.
  • Curve Radius (Min): 40 mm.
  • Movement Vertical (Max): 24 mm.
View other configurations.

Lifting Force Specifications

Vacuum Level Lifting Force Direction
20 -kPa 74 N Vertical to the Surface
40 -kPa 0 N Vertical to the Surface
50 -kPa 0 N Vertical to the Surface
60 -kPa 167 N Vertical to the Surface
90 -kPa 226 N Vertical to the Surface
10 -kPa 0 N Parallel to the Surface
20 -kPa 62.4 N Parallel to the Surface
40 -kPa 0 N Parallel to the Surface
60 -kPa 122.4 N Parallel to the Surface
90 -kPa 154.1 N Parallel to the Surface

Material Quality Specifications

Material Quality
Wear Resistance Good
Oil Poor
Weather Ozone Excellent
Hydrolysis Fair
Petrol Poor
Concentrated Acids Poor
Alcohol Good
Ethanol Not applicable
Methanol Not applicable
Oxidation Excellent
