Piab B75.37.07UB / 0128122 Suction cup B75 HNBR, 3/8" NPSF female Al, with mesh filter

Piab’s HNBR bellow suction cups are engineered for high-performance handling in challenging industrial settings. Made from HNBR, these cups provide outstanding resistance to heat, oil, and chemicals. The flexible bellow design allows for excellent adaptab.

$106.85
Part Numbers
  • B75.37.07UB
  • 0128122
Highlights...

Features

  • Manufactured from high-performance, mark free HNBR rubber
  • Outstanding resistance to heat, oil, and chemicals
  • Flexible bellow design for adapting to surface variations
  • Secure and reliable grip in demanding applications
  • Durable construction for extended service life
  • Perfect for automotive and heavy-duty industrial use
  • Material Temperature Max: 284 °F
  • Fitting Size: 3/8" mm.
  • Curve Radius (Min): 40 mm.
  • Movement Vertical (Max): 24 mm.
View other configurations.

Lifting Force Specifications

Vacuum Level Lifting Force Direction
20 -kPa 74 N Vertical to the Surface
40 -kPa 0 N Vertical to the Surface
50 -kPa 0 N Vertical to the Surface
60 -kPa 167 N Vertical to the Surface
90 -kPa 226 N Vertical to the Surface
10 -kPa 0 N Parallel to the Surface
20 -kPa 62.4 N Parallel to the Surface
40 -kPa 0 N Parallel to the Surface
60 -kPa 122.4 N Parallel to the Surface
90 -kPa 154.1 N Parallel to the Surface

Material Quality Specifications

Material Quality
Wear Resistance Excellent
Oil Excellent
Weather Ozone Excellent
Hydrolysis Good
Petrol Excellent
Concentrated Acids Fair
Alcohol Good
Ethanol Not applicable
Methanol Not applicable
Oxidation Excellent
