Piab B40.10.04DE / 0101467 Suction cup B40 Chloroprene, 3/8" NPT male, with dual flow control valve

Piab’s chloroprene bellow suction cups are designed for versatile and durable handling in a wide range of industrial applications. Made from high-quality chloroprene rubber, these cups offer excellent resistance to oils, weathering, and abrasion. The flex.

$34.40
Part Numbers
  • B40.10.04DE
  • 0101467
Highlights...

Features

  • Made from high-quality chloroprene rubber
  • Excellent resistance to oils, abrasion, and weathering
  • Flexible bellow design adapts to curved and uneven surfaces
  • Mark free handling
  • Durable for long-lasting use in demanding environments
  • Ideal for automotive, packaging, and general manufacturing
  • Material Temperature Max: 230 °F
  • Fitting Size: 3/8" mm.
  • Curve Radius (Min): 20 mm.
  • Movement Vertical (Max): 13.5 mm.
View other configurations.

Lifting Force Specifications

Vacuum Level Lifting Force Direction
20 -kPa 22 N Vertical to the Surface
40 -kPa 0 N Vertical to the Surface
50 -kPa 0 N Vertical to the Surface
60 -kPa 39 N Vertical to the Surface
90 -kPa 49 N Vertical to the Surface
10 -kPa 0 N Parallel to the Surface
20 -kPa 17.1 N Parallel to the Surface
40 -kPa 0 N Parallel to the Surface
60 -kPa 26.3 N Parallel to the Surface
90 -kPa 30.5 N Parallel to the Surface

Material Quality Specifications

Material Quality
Wear Resistance Excellent
Oil Fair
Weather Ozone Good
Hydrolysis Good
Petrol Fair
Concentrated Acids Poor
Alcohol Good
Ethanol Not applicable
Methanol Not applicable
Oxidation Good
