Piab D20-2.20.02DC / 0101234 Suction cup D20-2 Silicone, 1/8" NPT male, with dual flow control valve
Used for curved and irregular surfaces. Can lift even over corners and edges. Not suitable for use on flat surfaces.
$24.66
Part Numbers
- D20-2.20.02DC
- 0101234
Highlights...
- D20-2.20.02DC
- By Piab
- FREE Shipping on orders of $2,000 or more
Overview
Features
- Suitable for objects with curved or irregular surfaces
- Grips around corners and edges.
- Material Temperature Max: 392 °F
- Fitting Size: 1/8" mm.
- Curve Radius (Min): 8 mm.
- Movement Vertical (Max): 2.8 mm.
Description
Lifting Force Specifications
| Vacuum Level | Lifting Force | Direction |
|---|---|---|
| 20 -kPa | 5.9 N | Vertical to the Surface |
| 40 -kPa | 0 N | Vertical to the Surface |
| 50 -kPa | 0 N | Vertical to the Surface |
| 60 -kPa | 15 N | Vertical to the Surface |
| 90 -kPa | 18 N | Vertical to the Surface |
| 10 -kPa | 0 N | Parallel to the Surface |
| 20 -kPa | 5 N | Parallel to the Surface |
| 40 -kPa | 0 N | Parallel to the Surface |
| 60 -kPa | 8 N | Parallel to the Surface |
| 90 -kPa | 8.5 N | Parallel to the Surface |
Material Quality Specifications
| Material | Quality |
|---|---|
| Wear Resistance | Good |
| Oil | Poor |
| Weather Ozone | Excellent |
| Hydrolysis | Fair |
| Petrol | Poor |
| Concentrated Acids | Poor |
| Alcohol | Good |
| Ethanol | Not applicable |
| Methanol | Not applicable |
| Oxidation | Excellent |
