Piab 02.09.783 Vane pump 400 IE3 460V, 208V,230V

Call for pricing
Part Numbers
  • 02.09.783
  • 0209783
Highlights...

Features

  • Electro mechanical generated vacuum
  • High vacuum flow
  • Integrated inlet filter and control valves
  • Oil-free
  • Vibration stable
  • Material: Iron FE
  • Weight (Max): 118000 oz.
  • Item Feed Pressure (Max): 0
  • Item Noise Level (Max): 79
View other configurations.

Ejector Data Specifications

Ejector Specification Vane pump 400 60Hz
Feed Pressure | MPa 0
Air Consumption | Nl/s 0
Vacuum (Max) | -kPa 80
Frequency | Hz 60
Vacuum Flow at 0 -kPa | Nl/s 42.8
Vacuum Flow at 10 -kPa | Nl/s 38.1
Vacuum Flow at 20 -kPa | Nl/s 33.3
Vacuum Flow at 30 -kPa | Nl/s 28.6
Vacuum Flow at 40 -kPa | Nl/s 23.9
Vacuum Flow at 50 -kPa | Nl/s 19.2
Vacuum Flow at 60 -kPa | Nl/s 14.4
Vacuum Flow at 70 -kPa | Nl/s 9.7
Vacuum Flow at 80 -kPa | Nl/s 5
