Piab B50-2.21.05AC / 9910492

Piab’s FDA/EU approved silicone bellow suction cups are engineered for safe and hygienic handling in food, pharmaceutical, and sensitive applications. Made from high-quality, compliant silicone, these cups offer exceptional flexibility and a gentle grip. .

$42.45
Part Numbers
  • B50-2.21.05AC
  • 9910492
Highlights...

Features

  • The silicone material complies with FDA 21 CFR 177.2600 & EU 1935/2004.
  • Suitable for level adjustment.
  • Several short bellows in one lifting device can handle objects with height differences and varying shapes, for example embossed or corrugated plates.
  • The lifting movement can be used to separate small and thin objects.
  • Only lightweight objects should be handled when the lifting force is parallel to the surface of the object, in order to achieve good precision and safe lifting movement.
  • Material Temperature Max: 392 °F
  • Fitting Size: 1/4" mm.
  • Curve Radius (Min): 30 mm.
  • Movement Vertical (Max): 12.4 mm.
View other configurations.

Lifting Force Specifications

Vacuum Level Lifting Force Direction
20 -kPa 33 N Vertical to the Surface
40 -kPa 0 N Vertical to the Surface
50 -kPa 0 N Vertical to the Surface
60 -kPa 65 N Vertical to the Surface
90 -kPa 82 N Vertical to the Surface
10 -kPa 0 N Parallel to the Surface
20 -kPa 24.2 N Parallel to the Surface
40 -kPa 0 N Parallel to the Surface
60 -kPa 51.2 N Parallel to the Surface
90 -kPa 60.8 N Parallel to the Surface

Material Quality Specifications

Material Quality
Wear Resistance Good
Oil Poor
Weather Ozone Excellent
Hydrolysis Fair
Petrol Poor
Concentrated Acids Poor
Alcohol Good
Ethanol Not applicable
Methanol Not applicable
Oxidation Excellent
