Sick 6049061 / FFUS20-1C1IO Flow Sensor

Non-contact flow sensor with ultrasonic technology. Analog output, 1 pulse/status output, PNP/NPN transistor output, empty pipe detection, dosing output signaling. DN 20 nominal width of measuring tube. Clamp (DIN 11864-3) connection.

$1,222.00
Effective August 29th, 2025 SICK has added a 9.8% surcharge for all of their products. The surcharge will appear as a separate line item on each sales order.
Part Numbers
  • FFUS20-1C1IO
  • 6049061
Highlights...

Features

  • Dn 20 nominal width measuring tube
  • ≤ 60 l/min maximum flow
  • Ppsu, EPDM wetted parts
  • Clamp (din 11864-3) process connection
  • Analog output 4 ma to 20 ma, 0 ma to 20 ma current flow and temperature, 1 pulse/status output pnp/npn-transistor output for flow rate meter, empty pipe detection, flow monitoring, dosing output, flow direction (dependent on type) output signal
  • 0 °c to +80 °c process temperature
  • ≤ 10 bar process pressure
View other configurations.
