Sick 6076635 / PBT-CB1X1SG3SE0A2A0Z Pressure Sensor

4 to 20mA, 2-wire output pressure sensor. Compound pressure pressure, –1 to 1bar measuring range. ≤ ± 1 % of the span accuracy. G ⅜ B according to EN 837 connection.

$297.00
Effective August 29th, 2025 SICK has added a 9.8% surcharge for all of their products. The surcharge will appear as a separate line item on each sales order.
Part Numbers
  • PBT-CB1X1SG3SE0A2A0Z
  • 6076635
Highlights...

Features

  • Compound pressure pressure type
  • Bar pressure unit
  • –1 bar to 1 bar measuring range
  • ≤ ± 1 % of the span accuracy
  • ≤ ± 0.5 %, of the span non-linearity
  • G ⅜ b according to EN 837 process connection
  • Standard pressure port
  • –30 °c to +100 °c process temperature
  • Without seal seal
  • 4 ma to 20 ma, 2-wire output signal
  • Flying leads, 2 m connection type
  • Ip67 enclosure rating
  • 8 v DC to 30 v DC supply voltage
  • Without specialty
View other configurations.
