Sick 6086093 / PBT-RB010AG2SF0W5A0Z Pressure Sensor

1 to 5V, 3-conductor output pressure sensor. Gauge pressure pressure, 0 to 10bar measuring range. ≤ ± 0.5 % of the span accuracy. G ¼ female connection.

$438.00
Effective August 29th, 2025 SICK has added a 9.8% surcharge for all of their products. The surcharge will appear as a separate line item on each sales order.
Part Numbers
  • PBT-RB010AG2SF0W5A0Z
  • 6086093
Highlights...

Features

  • Gauge pressure pressure type
  • Bar pressure unit
  • 0 bar to 10 bar measuring range
  • ≤ ± 0.5 % of the span accuracy
  • ≤ ± 0.25 %, of the span non-linearity
  • G ¼ female process connection
  • Standard pressure port
  • –20 °c to +100 °c process temperature
  • Without seal seal
  • 1 v to 5 v, 3-conductor output signal
  • Flying leads, 5 m connection type
  • Ip67 enclosure rating
  • 8 v DC to 30 v DC supply voltage
  • Without specialty
View other configurations.
