Sick 6062989 / PBT-RB6X0SGESE0VLC0Z Pressure Sensor
0 to 10V, 3-wire output pressure sensor. Gauge pressure pressure, 0 to 6bar measuring range. ≤ ± 1 % of the span accuracy. G ½ B according to EN 837 connection.
$231.00
Effective August 29th, 2025 SICK has added a 9.8% surcharge for all of their products. The surcharge will appear as a separate line item on each sales order.
Part Numbers
- PBT-RB6X0SGESE0VLC0Z
- 6062989
Highlights...
- PBT-RB6X0SGESE0VLC0Z
- By SICK
- FREE Shipping on orders of $1,000 or more
Overview
Features
- Gauge pressure pressure type
- Bar pressure unit
- 0 bar to 6 bar measuring range
- ≤ ± 1 % of the span accuracy
- ≤ ± 0.5 %, of the span non-linearity
- G ½ b according to EN 837 process connection
- Standard pressure port
- –30 °c to +100 °c process temperature
- Without seal seal
- 0 v to 10 v, 3-wire output signal
- L-connector acc. to DIN 175301-803 a connection type
- Ip65 enclosure rating
- 14 v DC to 30 v DC supply voltage
- Without specialty
