Sick 6075644 / LBV311-GXACVNVMX Level Sensor

NAMUR signal output level sensor. 160 mm probe length, with Stainless steel (investment casting) 316L housing material. –50 to 150°C range, with Tri-Clamp 2'' (316L, Ra < 0.8 μm) connection.

$2,021.00
Effective August 29th, 2025 SICK has added a 9.8% surcharge for all of their products. The surcharge will appear as a separate line item on each sales order.
Part Numbers
  • LBV311-GXACVNVMX
  • 6075644
Highlights...

Features

  • Tri-clamp 2'' (316l, ra < 0.8 μm) process connection
  • Namur signal output signal
  • 160 mm probe length
  • Stainless steel (investment casting) 316l housing material
  • M20 x 1.5 connection type
  • –50 °c to +150 °c process temperature
  • Bvs 17 ATEX e 098 x / ATEX II 1d, 1/2d, 2d ex ta ta/tb tb IIIC tx da, da/db, db authorizations
View other configurations.
