Sick 6053263 / LBV311-CXAZFNVMX Level Sensor

NAMUR signal output level sensor. 160 mm probe length, with Stainless steel (investment casting) 316L housing material. –50 to 150°C range, with Flange DN 100 PN 6 Form C, DIN2501/ 316L connection.

$2,214.00
Effective August 29th, 2025 SICK has added a 9.8% surcharge for all of their products. The surcharge will appear as a separate line item on each sales order.
Part Numbers
  • LBV311-CXAZFNVMX
  • 6053263
Highlights...

Features

  • Flange DN 100 PN 6 form c, din2501/ 316l process connection
  • Namur signal output signal
  • 160 mm probe length
  • Stainless steel (investment casting) 316l housing material
  • M20 x 1.5 connection type
  • –50 °c to +150 °c process temperature
  • Ptb 17 ATEX 2016 x / ATEX II 1g, 1/2g, 2g ex ia IIC t6 ga, ga/gb, gb authorizations
View other configurations.
